Description:

The GTO/PRO SL2000B series will handle gates weighing up to 1000 lbs. (453.6 kg) and 30 ft. (9.1 m) in length with a 20 ft. (6.1 m) opening, if all proper installation procedures have been followed. Note: ball bearing rollers should be used on all gates.

The PRO SL2000B should be used on driveway gates in residential or light commercial settings that have gates constructed of aluminum, steel, wood, or chain link. The PRO SL2000B can be plugged into any standard house outlet using the provided transformer so there is no need for an electrician. If a power outlet is not within 2000' the PROSL2000B can still be operated using solar panels. All power for the motor and accessories are drawn from an included 12V DC battery, which is also used to power the motor during loss of power. The internal battery comes with a standard 12 month warranty but generally lasts between 3-5 years depending on environment and usage conditions.

The Pro SL2000B Gate Openers feature a Heavy Duty SL2000B Series Control Board that provides unique control over the opening and closing slide gates. The Control Board highlights adjustable obstruction sensing in both open and close modes to minimize damage to the gate and the obstruction during periods of impediment. The control board also allows the user to adjust their system for auto closing and gate sequencing. The Pro SL2000B also includes a heavy-duty transformer, built to resist power surges and static charges. The Pro SL 2000B is fully capable and ready to add accessories and modify the system to reflect the user's system needs. The Pro SL 2000B can be modified to work with GTO accessories including: solar panels, gate transmitter, exit wand, digital keypad, and more.

Features:

• Full systems capable "add on ready" heavy-duty dontrol board includes adjustable obstruction sensing, gate sequencing and auto close settings (0-120 seconds).
• Includes a built-in internal friction disk brake/lock
• Small footprint for tight spaces.
• Easy to install 4' (1.2m) long post mount provided.
• Chain disconnect for manual operation.
• Light professional and residential cycle rated to 100 cycles daily.
• UL rated for Class I, II, and III. System certified to be in compliance with UL 325, 5th edition.

Specifications:

Mechanical:

• The GTO/PRO control board can be programmed for left-to-right or right-to-left opening.
• Temperature rating: -5 F (-28 C) to +160 F (+93 C)
• Opening Time: 1 foot (.31m) per second.
• Adjustable auto close, obstruction sensitivity and dual gate sequencing.
• One button auto-memorization of digital transmitter code.
• Charging regulated circuit on control board. "Sleep draw" is 40 mA; "Active draw" is 2 to 9 amps.
• GTO/PRO remote-mounted 318 MHz RF receiver and one button transmitter. Included.
• Fully compatible accessory terminal block provides connections for safety loops, wands, intercoms, card readers, phone systems.

Electrical/Power:

• 12 Volt DC / 7.0 amp hour, sealed, rechargeable battery (included)
• Battery charge maintained by a 120V AC/60 Htz input and 18V AC at 40VA output transformer rectified to 14V DC through control board.
• Large battery (FP295) recommended in higher cycle or solar applications.

Other:

• Shipping Weight: 84 lbs. (38 kg)
• Meets UPS shipping standards.
• Safety Listings: System Certified with UL325 5th Edition safety standards, ETL listed.

Manual:

Click here to view the product manual and manufacturer's warranty.
